Countertop | Floor | Wall

Coal

Fixture

Fixture™ is sleek, concrete look ColorBody™ porcelain tile, engineered for optimal durability and available in five natural colors in polished and matte finishes, this impressive tile ranks high for strength and beauty.

: FX24
: 3/8
: 12X24
: Textured
: V2: Medium
: Portugal
: FX24
: 3/8, 5/16
: 12X24, 24X48
: Matte
: V2: Medium
: Portugal
: FX24
: 3/8, 5/16
: 12X24, 24X48
: Polished
: V2: Medium
: Portugal
: FX24
: 5/16
: 24X24
: Matte
: V2: Medium
: Portugal
: FX24
: 5/16
: 24X24
: Polished
: V2: Medium
: Portugal
: FX24
: 3/8
: 24X24
: Textured
: V2: Medium
: Portugal
  • Application
    Target Dcof Wet Suitable
    Dry & Level - Interior Floor N/A
    Wet & Level - Interior Floor ≥0.42
    Shower Floors (Residential or Light Commercial) ≥0.42
    Exterior Floor Applications (including pool decking & other wet areas with minimal footwear) ≥0.60
    Ramps & Inclines ≥0.65
    Walls/Backsplashes N/A
    Countertops N/A
    Pool Linings N/A
    1/8"

    ●  A DCOF value of greater than or equal to 0.42 is the standard for tiles specified for level interior spaces expected to be walked upon when wet, as stated in ANSI A137.1-A326.3. For more information about DCOF and the DCOF AcuTest™, visit daltile.com/DCOF.

    ●  Manufacturer Advisory: All tile is measured by the DCOF AcuTestTM method. Tiles with DCOF values less than 0.42 are not recommended for use in areas with wet or slippery conditions. For more information, see ANSI standard A137.1 section 6.2.2.1.10, available at www.tileusa.com.

    ●  Suitable for exterior applications in freezing and non-freezing climates, when proper installation methods are followed.

  • Technical Specifications
    Test Method Result
    Water Absorption ASTM C373 < 0.5
    Breaking Strength ASTM C648 > 275 lbs
    Scratch Hardness ASTM MOHS 8
    Chemical Resistance ASTM C650 Resistant
  • Durability Chart
    Floor Surface Wear Resistance
    1 - Residential Bathrooms
    2 - All Residential Areas
    3 - All Residential / Light Commercial
    4 - All Residential / Commercial

Available Trim (4)

Bullnose
Bullnose
3X24
Shape Number: S43F9
Bullnose
Bullnose
3X24
Shape Number: S43F9
Cove Base
Cove Base
6X12
Shape Number: S36C9
Cove Base Outcorner
Cove Base Outcorner
1X6
Shape Number: SC36C9
